Synology Mesh Router MR2200AC

Synology Mesh Router MR2200AC

It's not just another Wi-Fi system.
It's better Wi-Fi and safer Internet ahead

Coming with intelligent mesh Wi-Fi capability and best-in-class parental controls, MR2200ac is designed to keep all devices connected and everyone safe. Experience the award-winning Synology Router Manager (SRM) with an MR2200ac, and add more when you are ready to expand your coverage even further.

Smart Wi-Fi all around

Multiple MR2200ac can work together as a system to bring Wi-Fi to every corner of your home. Wherever you go, stay on a single Wi-Fi network and enjoy seamless connectivity from one place to another.

The intelligence behind your mesh network

The algorithms built into SRM make deployment incredibly easy. The system intelligently self-configures, self-optimizes, and even self-heals, always giving you the fastest possible path to the Internet.

Pick the ones you want to add to your network

Self-Configuring

Automatically selects the best topology

Whole-home Wi-Fi, easily managed

State-of-the-art technology doesn't have to be complicated. See how Wi-Fi Connect makes your mesh Wi-Fi straightforward – and powerful.

Real-Time Monitoring

This is your whole Wi-Fi system at a glance. The MR2200ac in the hallway got unplugged? You see it here.

Mash networking at work

A beautiful network map visualizes how your Wi-Fi points are interconnected and whether they are using 5GHz, 2.4GHz, or Ethernet uplinks.

Identify Bottlenecks

Run performance tests to pinpoint what might be slowing down your network.

Customize guest network optiosn

Set up a welcome portal for everyone connecting to your guest Wi-Fi. Tools like scheduling, auto password change, and MAC filters can help keep unwanted connections away.

Create a kid-friendly online world

We want kids to be safe online, even when we’re not there. Safe Access helps you lay down rules for each kid without having to look for parental control solutions for every devices. Now you can get a full picture of how they’re exploring the world every day, and protect them until they’re ready.

Profile

Create a user profile to manage all devices someone owns at one time. You can also have one for all future devices connecting to your local network, one for guest Wi-Fi, one for IoT gadgets, and so on.

Time Management

Set time limits and schedules. Encourage your kids to use their time wisely, and reserve some quality time for family.

Internet filtering

Safeguard kids from adult-only content and search results. Set up a whitelist so younger children can only visit those sites. Schedule a web filter to ensure no social media during homework hours.

Understand usage & react

Gain insights into a kid’s activities every day. Reward him by giving him a few extra hours online, or pause all his devices if it’s time to talk.

Security at the perimeter

It's not just people that you need to protect. It's all the connected things: IP cameras, smart doorbells, alarm systems… things that can make a smart home vulnerable. MR2200ac installs multiple layers of protection to shield your network against cyberattacks happening every day.

Latest Defense

Wi-Fi Certified WPA3 & Enhanced OpenTM technology

Certified by the newest Wi-Fi security standards including WPA3-Personal, WPA3-Enterprise and Opportunistic Wireless Encryption (OWE), MR2200ac equips home, business, and open Wi-Fi networks with better defenses against snooping and other attacks. 1

Always up-to-date

Boasting a long track record of fast and continuous updates, SRM makes sure that your mesh network is ready to counter emerging threats.

Built-in security databases

Google Safe Browsing

Guarding over 3 billion devices from malware, social engineering, and unwanted software, it's now brought onto MR2200ac to keep everything in your network safe, regardless of the platforms they use.

DNS & IP threat intelligence

Several additional threat intelligence databases are integrated to block access to malicious domains and IPs. All events are logged for auditing purpose.

Advanced functionality made accessible

For small offices who don't want the hassle of wiring access points everywhere, a mesh Wi-Fi solution fits in perfectly. Unlike others, MR2200ac doesn't leave out the network management features businesses care about.

Granular Quality of Service (QoS)

Device- or application-based bandwidth control and traffic reports.

Intuitive and high-speed VPN

Business-grade SSL VPN, WebVPN, and Site-to-Site IPsec VPN.

File sharing & backup

Time Machine backup, remote file sharing, media server, and much more.

Be mobile

Deploy a mesh network from your phone. Stay on top of the traffic usage, user activities, and security events wherever you are, and act on them with just one tap on the screen. With DS router, you're never too far away from home.

Build your own Wi-Fi system

Single MR2200AC

  • 2,000 ft2 / 185 m2
  • Perfect for apartments and small homes.

Multiple MR2200AC

  • Every additional unit adds 2,000 ft2 / 185 m2
  • For larger homes that want to blanket the house with smarter Wi-Fi and safer access to the Internet.

RT2600ac + MR2200ac

  • Starts from 5,000 ft2 / 464 m2
  • For offices or tech enthusiasts who want to make the most of SRM's powerful applications, including the intrusion prevention technology.
Hardware
ProcessorQuad core 717 MHz
Memory256 MB DDR3
Antenna type2×2 MIMO High Performance Hidden Antenna (2.4 GHz / 5 GHz)
LAN networkGigabit (RJ-45) x 1
WAN networkGigabit (RJ-45) x 1
External connectionUSB 3.0 x 1 (5V, 0.9A output power)
Button and switchWPS, power, reset, Wi-Fi on/off
Exterior
Size (height x width x depth)154 mm x 199 mm x 65 mm
weight0.45 kg
temperature
Working temperature5°C to 40°C (40°F to 104°F)
Storage temperature-20 ° C to 60 ° C (-5 ° F to 140 ° F)
Relative humidity5% to 95% RH
Warranty2 years
other projects
AC input voltage100V to 240V AC
Current frequency50/60 Hz, single frequency
Power consumption12.95 W (access)
5.21 W (standby)
wireless
IEEE 802.11acIEEE 802.11a/b/g/n/ac
Synchronous tri-band Wi-Fi
5GHz-1: 867Mbps
5GHz-2: 867Mbps
2.4GHz: 400Mbps
IEEE 802.11ac wave 2MU-MIMO
Wi-Fi encryptionWEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA2/WPA3-Personal, WPA3-Personal/Enterprise, Wi-Fi Enhanced Open (OWE)
Wi-Fi Mac address filter
Network entity address filtering rule limit64
Seamless roaming802.11k/v/r standard support
Beamforming
DFS
Scheduled Wi-Fi connection
Guest network
Visitor entrance
Customized interface design
Connection time limit
Password rotation
WPS 2.0 (Wi-Fi Protected Setup 2.0)
3G / 4G NIC & USB Network Sharing
Maximum number of connected devices90
Wi-Fi node
Primary Wi-Fi node
network
Internet connectionDynamic IP, Static IP, PPPoE, PPTP, DSL-Lite (AFTR)
3G/4G LTE network card
Android network sharing
iPhone network sharing
RemarksiPhone network sharing only supports SRM 1.2 and newer Synology Router
Operating modeWireless Router
Wireless AP
Connection transferCan be set manually or via UPnP
Connection transfer rule limit64
UPnP rule limit64
Connection trigger
Connection trigger rule upper limit32
Connection trigger timeout time lower limit30s
Connection trigger timeout time limit3600s
DMZ
IPv6IPv6 DHCP server/client, DS-Lite, 6in4, 6to4, 6rd, dual stack, DHCPv6-PD, IPv6 trunk, FLET’s IPv6
DHCPServer/client mode, client list, MAC address reservation
DHCP reservation limit500
LAN/WLAN IGMP snooping
VPNVPN server (WebVPN, SSL VPN, SSTP, OpenVPN, L2TP/IPSec, PPTP, Site-to-Site)
VPN client (PPTP, OpenVPN, L2TP/IPSec)
VPN pass-through (PPTP, IPSec, L2TP)
Policy routing, static routing, network address translation (NAT), PPPoE forwarding
IPv4 static route limit100
IPv6 static route limit100
Diagnostic toolsPing
Path tracking
Safe Access
Parental Control
User setting15
Network settings2
Customized network scheduling
Hours of use
IPv4/IPv6 DNS-based web filterschedule
database
Unblock request
Customized allow and block listMaximum blocked URLs: 100
Maximum allowed URLs: 100
Interrupt network
reward
Record
Return
safety
Safe searchBing, Google, YouTube
Intelligent threat databaseSupport for IPv4 and IPv6
Google Safe BrowsingSupport for IPv4 and IPv6
Automatic database updateThreat Intelligence Database, Google Safe Browsing, DNS-based web filter
flow control
Network blocking, device speed limit, traffic priority
Application layer (Layer 7) quality of service (QoS)
Device rule limit64
Application rule limit per device32
data monitoring
Instant image
Historical statisticsOn a daily, weekly, monthly, and yearly basis
Website browsing record
Application detection
Traffic report
Automatic location update
Scheduleable
Traffic analysis cycleOn a daily, weekly, monthly, and yearly basis
Export format.CSV, .HTML
VPN Plus Server
VPN Plus ServerEasily establish and manage secure access to VPNs through a web browser or client. Support multiple VPN servers: Site-to-Site, WebVPN, SSL VPN, Remote Desktop, SSTP, OpenVPN, L2TP over IPSec and PPTP
Maximum number of connections10
Site-to-Site VPN
Site-to-Site Tunnels4
Remote desktop (RDP + VNC)3
Contact list
Record
Return
Kit center
Cloud Station ServerSynchronize data across multiple platforms and centralize the history of all important files on your router
Maximum number of file sync transfers64
RemarksCloud Station ShareSync is not supported
DNS ServerFinding and translating a web domain name is called an IP address.
Download StationSupported download agreement: BT/HTTP/FTP/NZB/eMule
Download task limit50
BT task limit20
Media Server (DLNA/UPnP®)Multimedia index
DLNA compatible
Support for PS3/PS4/Xbox 360/Xbox One
RADIUS ServerFully integrated authentication, authorization, and account processing services for wireless network access
Mobile app
DS router (Android/iOS)Initial installation
Network overview
Wi-Fi management
Wi-Fi system deployment
Safe Access
flow control
Network security (firewall, connection, transfer, internet blockade)
Wake on LAN
system update
VPN Plus (Android/iOS)
DS cloud (Android/iOS)
DS get (Android)
DS file (Android/iOS)
management
SystemSynology Router Manager (SRM)
Operating system upgrade (free)
Access SRM anywhereSynology QuickConnect and Dynamic DNS (DDNS)
safetyFirewall/SPI firewall, DoS protection, VPN passthrough (PPTP, IPSec, L2TP), automatic blocking, SSL authentication, security consulting center, two-factor authentication
Wake on LAN (WOL)
Wake on LAN via QuickConnect
Maximum number of connected devices100
Message notificationEmail, SMS, push service (via DS router)
SSH
SNMP
Set backup & restore
User account management
Printer serverMaximum number of printers: 1
USB / SD card file service
File systemEXT4, FAT, NTFS, HFS+
Support access methodFile Manager (local network only)
Web browsers: ChromeTM, Firefox®, Internet Explorer®: 11 onwards, Safari® 11 onwards
Mobile device: DS file
Supported communication protocolWindows File Service (CIFS), Mac File Service (AFP), FTP/FTPS, WebDAV
Apple Time Machine
Shared folder permissions
Storage space sleep
Environment and packaging
surroundingsRoHS compliant
Package contentsHost X 1
Transformer X 1
RJ-45 web route X 1
Quick Installation Guide X 1
